| Typical Performance Characteristics (@100 PSIG air supply pressure):
- 59.7 in3/min @ 7000 psig
- 29.9 in3/min @ 15000 psig
Materials of Construction:
- Pump section: Separation – All SS
- Plunger: 440C SS hard-chrome plated
- Non-metallics: PTFE, Viton
Applications:
- Service Code 1: Petroleum-based oils, kerosene, ethylene glycol, water with 5% soluble oil.
- Service Code 2: Plain water, diesel fuel
- Service Code 3: Most phosphate ester-based fire-resistant hydraulic
fluids (e.g. Pydraul, Lindol, Cellulube, Fyrquel and Houghtosafe 1120)
and petroleum-based solvents compatible with UHMWPE (Ultra-high
Molecular Weight Polyethylene) dynamic seals and Viton static seals.
- Service Code 4: Petroleum-based solvents / aromatic hydrocarbons
(e.g. benzene, toluene, xylene, hylene, etc.); chlorinated solvents
(trichloroethylene, carbon tetrachloride, chlorobenzene, etc.);
mercaptans; Dowtherm A; fluorinated solvents (fluorobenzene,
fluorochloroethylene, etc.); Dowtherm E; plus all of Group 3 and some
mildly corrosive acids compatible with wetted materials.
- Service Code 5: Skydrol and Aerosafe hydraulic fluid; acetone and some alcohols (ethyl, methyl, and isopropyl).
- Service Code 6: N/R
|
